Hisaka

General 2-Way Floating Ball Valve

Model HF5, HF5-TD, TS, HF5-AD, AS

• Rating JIS10K, ANSI 150Lb
• Size 1/2"(15A) - 12"(300A)
• Material SCS13A (CF8), SCS14A, SCS16A (CF3), A216-WCB (available for size above 5”), FCD450, FC200 etc.

• Rating JIS20K, ANSI 300Lb
• Size 1/2"(15A) - 10"(250A)
• Material SCS13A, SCS14A (CF8M), SCS16A (CF3), A216-WCB (available for size above 5”) etc.

3 Way Ball Valve (T-port & L-port)

Model H45

• atingG JIS10K, ASME 150#
• Size 1/2"(15A) - 12"(300A)
• Material SCS13A (CF8), SCS14A (CF8M), SCS16A (CF3), A216-WCB (available for size above 5”), FCD450, FC200 etc.

Type Y-Type, 3-Way Driverting Ball Valve

Model HY1(M), HY2(M)

• Rating JIS10K, ASME 150#
• Size 1/2"(15A) - 12"(300A)
• Material SCS13A (CF8), SCS14A (CF8M), SCS16A (CF3), A216-WCB (available for size above 5”), FCD450, FC200 etc.

Type Metal Touch Ball Valve

MODEL HF5(M) SERIES (HF5(M1R)• HF5(M1M)• HF5(M1H)

• Rating JIS10K, JIS20K, ASME 150#, ASME 300#
• Size 15A(1/2”) ~ 200A(8”)
• Material SCS13A (CF8), SCS14A (CF8M), SCS16A (CF3) etc.

Full Jacket 2-Way Ball Valve

Model HJ5

• Rating JIS10K, ASME 150#
• Size 15A(1/2”) ~ 300A(12”)
• Material SCS13A (CF8), SCS14A, SCS16A (CF3) etc.

• Rating JIS10K, ASME 300#
• Size 15A(1/2”) ~ 250A(10”)
• Material SCS13A, SCS14A (CF8M), SCS16A etc.

Type For Steam Application Ball Valve

Model HF5(ST)

• For 1 Mpa
• Rating JIS10K, ASME 150#
• Size 15Ａ(1/2") ~ 150Ａ(6")
• Material FC200, FCD450 etc.

• For 2 Mpa
• Rating JIS 20K, ASME 300#
• Size 15Ａ(1/2") ~ 100Ａ(4")
• Material SCS13A (CF8), SCS14A (CF8M), SCS16A (CF3), A216‐WCB (available for size above 5”) etc.

Type Low Temperature Service

Model HF(LT)

• Rating JIS10K,ASME150#
• Size 15A(1/2”) ~ 100A(4”)
• Material SCS13A (CF8), SCS14A (CF8M) and others.
• TEMPERATURE －50°C ~

Type Tank Bottom Ball Valve

Model TB5

• Rating JIS10K, JIS20K, ASME 150#, ASME 300#
• Size 15A(1/2”) ~ 200A(8”)
• Material SCS13A (CF8), SCS14A (CF8M), SCS16A (CF3) etc.
